GPS Tracker ES600HC03

Features

4G Connectivity

Supports 2G/4G dual-network; LTE/GSM multi-band, compatible with Southeast Asia, Africa, South America 2G/4G networks

Location Tracking

GPS+BDS dual-mode positioning, GPS positioning accuracy ＜10m

Playback and Download

Supports historical route playback and GPRS data upload, applicable for fleet management

Fast Start

GPS cold start positioning in 33s, fast positioning response

Alarms

Supports vibration alarm, power-off alarm and overspeed alarm for real-time abnormal alerts

Parameters Setting

Supports custom parameter setting and third-party inspection function

Battery

Built-in 10000mAh lithium battery, battery life about 60-70 days, support recharge and re-installation

Power Supply

DC 3.7V working voltage with stable power supply

Certificate

Certified by CE, FCC, Rohs, Reach and intertek

Customization

Supports LOGO customization for personalized needs

Communication Protocol

Supports GPRS communication protocol for stable data upload

Specification parameters

Size

105(L)*60(W)*25.5(H)mm

Weight

260g

Operating temperature

-25~+-80℃

Built-in battery

10000mAh

working voltage

3.7V DC

Hardware specifications

Positioning accuracy

GPS<10m

GSM frequency band

SIMCOM A7670E

LTE:B1/B3//B5/B7/B8/B20

GSM:900/1800

Web standards

SIMCOM A7670SA

LTE:B1/B2/83/84/85/B7/B8/B28/B66

GSM:850/900/1800/1900

(Mainly supports Southeast Asia 4G, Southeast Asia 2G+4G, Africa 2G, Africa 2G+4G, South America 4G, South America 2G+4G)

GSM antenna

BD&GPS dual-mode ceramic antenna

Communication four band antenna

Communication chip

ASR1603C

Positioning chip

CC1167Q

GPS sensitivity

-148dBm

GPS deviation

-143dBm

Tracking sensitivity

-159dBm

Positioning time

Cold start 33s

Software Specification Description

Parameter settings

support

Third-party inspection

support

GPRS upload

support

Overspeed alarm

support

Flee management

support

Historical route

support
