GPS Tracker ES600KA04

Features

4G Connectivity

Supports 4G network, multi-band LTE/GSM, compatible with Southeast Asia, Africa, South America 2G+4G/4G networks

Location Tracking

GPS+BDS dual-mode positioning with high-stability GPS antenna, GPS positioning accuracy ＜10m

Playback and Download

Supports regular tracking and GPRS data upload, with real-time vehicle tracking function

Fast Start

GPS cold start positioning in 33s, fast positioning response

Alarms

Supports power-off alarm, vibration alarm and overspeed alarm for real-time abnormal alerts

Parameters Setting

Supports custom parameter setting and third-party inspection function

Battery

Built-in 150mAh lithium battery

Power Supply

DC 9-90V wide working voltage with stable power supply

Certificate

Certified by CE, FCC, Rohs, Reach and intertek

Customization

Supports LOGO customization for personalized needs

Communication Protocol

Complies with JT/T808 standard protocol, supports GPRS communication protocol for stable data upload

Specification parameters

Size

75(L)*33(W)*17(H)mm

Weight

37g

Operating temperature

-25~+-80℃

Built-in battery

150mAh

working voltage

9-90V DC

Hardware specifications

Positioning accuracy

GPS<10m

Web standards

SIMCOM A76T0E

LTE:B1/B3/B5/87/B8/B20

GSM:900/1800     SIMCOM A7670SA

LTE::B1/B2/B3/84/B5/B7/B8/B28/B66     GSM:850/900/1800/1900

(Mainly supports Southeast Asia 4G,Southeast Asia 2G+4G,Africa 4G,Africa 2G+4G,South America 4G,South America 2G+4G)

Positioning time

Cold start 33s

GSM antenna

Dual mode BEIDOU and GPS ceramic antenna LTE quad band antenna

Communication chip

ASR1603C

Positioning chip

CC1167Q

GPS sensitivity

-143dBm

Tracking sensitivity

-159dBm

Software Specification Description

OTA update

support

Parameter settings

support

GPRS upload

support

Third-party inspection

support

Power outage alarm

support

Regular tracking

support

ACC detection

support

Vibration alarm

support

Overspeed alarm

support

Remote control & upgrade

support
